Comparison between XLPE Insulation Cable & PVC Insulation Cable

Difference between XLPE Insulation Cable & PVC Insulation Cable? Advantages of XLPE Insulated Power Cable

In today's fast-paced world, the demand for reliable and efficient power transmission solutions is more important than ever. Power cables play a crucial role in delivering electricity to our modern infrastructure. However, with so many options available in the market, choosing the right insulation material for your power cable can be a difficult task. The main purpose of the blog post is to provide a comprehensive comparison between XLPE insulation cable and PVC insulation cable, we also further read the advantages of XLPE Insulated Power Cable.

Difference between XLPE Insulation Cable & PVC Insulation Cable

Aspect XLPE Insulation Cable PVC Insulation Cable
Electric Load These cables are engineered to handle higher electrical loads with ease. These cables are designed for standard electrical loads.
Installation/Setup XLPE Insulation Cables require slightly more effort during installation. These PVC insulation cables are easy to install and suitable for straightforward setups.
Heat Resistance XLPE insulation cable offers good heat resistance, capable of withstanding higher temperatures without degradation. These PVC cables show the average heat resistance, suitable for standard operating temperatures.
Chemical Resistance Shows excellent resistance to chemicals Shows good chemical resistance
Maximum Operating Temperature Tolerance XLPE insulation cables can operate up to 90°C PVC insulation cables can handle temperatures up to 70°C
Short Circuit Temperature Tolerance XLPE Insulation Cable handles temperatures up to 250°C during short circuits. PVC Insulation Cable handles temperatures up to 160°C during short circuits.
Health Impact XLPE Insulation Cable Poses no health hazards as it does not release toxic substances under normal operating conditions. Since XLPE Insulated Cables don’t contain chloride, it is environmentally safe. PVC Insulation Cables are considered toxic due to the release of harmful substances during combustion or exposure to high temperatures
Durability XLPE Insulation Cables are durable but relatively less tough than PVC, requiring careful handling during installation and use. PVC Cables have good durability and resilience, able to withstand various mechanical stresses.
Diameter XLPE Insulated Cables have a smaller diameter PVC Insulation Cable has a larger diameter
Resistance to Oil XLPE Insulated Power Cable provides excellent resistance to oil PVC Insulation Cable offers moderate resistance to oil

What are the Advantages of XLPE Insulated Power Cable?

XLPE insulated power cables offer many advantages, these are as follows.

  • Light in Weight: XLPE insulated cables are lightweight, which makes them easier to transport, handle, and install, especially in large-scale projects.

  • Simple Accessories: Minimum tools and equipment are needed for the installation of XLPE insulated wires, further streamlining the installation process and reducing complexity. This simply means cost savings and efficiency for installers.

  • Strong Load Capacity: Strong load-carrying capacities enable XLPE insulated wires to easily handle large electrical loads.

  • High Heat Resistance: Excellent heat resistance is ensured by XLPE insulation, which enables the cables to function and remain undamaged even at high temperatures.

  • Strong Electrical Performance, Low Dielectric Loss: Strong electrical performance and low dielectric loss can be observed by XLPE insulated cables, which lead to effective power transmission and minimal energy loss.

  • Excellent Aging Resistance and Super Heat Deformation Resistance: XLPE insulation shows excellent ageing resistance, maintaining its performance and integrity over time even under harsh environmental conditions.

Let's sum up

In this article, we have discussed the key differences between XLPE Insulation Cables and PVC Insulation Cables. We have also read about the key advantages of XLPE Insulated Power Cables. Ultimately, the choice between XLPE and PVC insulated cables depends on the specific requirements of the application, such as the operating temperature, electrical load, environmental conditions and many more. While selecting between XLPE and PVC insulated cables, it's very important to select a manufacturer of XLPE Insulation Cables and PVC Insulation Cables who understands your specific needs and requirements. Quality should never be compromised, and the chosen manufacturer should consistently deliver the best solutions tailored to your application.
